Please discuss all options that are available with this model with our sales representative.
Mounted spare wheel and tyre
Full or part galvanised finish
Single wheels 15.3 x 6 stud – white with 10.0/75 x 15.3 x 10 ply tyres
Flotation 400/60-15.5 x 14 ply tyres
Custom made tray size available
Light board for concessional registration
Tray Size:
* 2.4m x 1.5m (8’x5′) tray (2T)
* 2.7×1.8m (9’x6′) tray (3T)
| Tipping mechanism: | Single acting two stage hydraulic ram run off tractor hydraulics |
| Headboard: | 25mm diameter tube |
| Sides: | Drop and removable |
| Tailgate: | Top and bottom hinged with manual lock |
| Tie rails: | 21mm diameter tube welded to sides |
| Suspension: | 50mm square solid steel axle welded to chassis |
| Wheels: | 14 x 6 stud - white |
| Tyres: | 6.50 x 16 x 18 ply |
| Jack stand: | Heavy duty drop leg on drawbar |
| Mudflaps: | White with Dean logo |
| Coupling: | Swivel ball end to suit 25mm pin |
| Brakes: | Unbraked |
| Length Overall: | 3.6m |
| Width Overall: | 1.93m |
| Tray Size: | (2.4m long x 1.5m wide) 2.7m long x 1.8m wide |
| Side height: | 320mm high |
| Load capacity: | (2.0Tonne) 3.0 tonne |
| ATM: | 3.62 tonne |
| Tare Weight: | 0.62 tonne |
