# Option to increase the carrying capacity to 2.3 tonne with Electric Breakaway brakes.
Flat top trailer that can be converted to a beavertail trailer with ramps that can carry a pay-load of 2.5tonne. It has an ATM of 3.5tonne.
| Headboard: | Combination 21mm diameter tube and pressed channel |
| Sides: | Drop and removable |
| Tailgate: | Bottom hinged with manual lock |
| Tie rails: | 21mm OD tube welded to sides and rear |
| Suspension: | AL-KO independent rubber suspension |
| Wheels: | 15 x 7 Landcruiser 6 stud - white |
| Tyres: | 225/70R15C light truck tyres |
| Mudguards: | Welded to tray |
| Mudflaps: | White with Dean logo |
| Jockey wheel: | Swivel 200mm heavy duty on drawbar |
| Coupling: | 50mm electric ball with safety chain |
| Lighting: | All LED multi-volt combination lamps |
| Electrical Connection: | Flat 7 pin plug |
| Brakes: | 10 inch electric breakaway brakes on both axles with Brake Safe Series 6000 unit |
| Spare wheel & tyre: | Mounted on trailer |
| Length Overall: | 4.951m |
| Width Overall: | 2.26m |
| Tray Size: | 3.6 long x 2.1m wide |
| Side height: | 330mm (Removable) |
| Load capacity: | 2.7 tonne |
| ATM: | 3.5 tonne |
| Tare Weight: | 0.8 tonne |
Extra cost. Final cost price to be calculated at the time of ordering and manufacturing.
Available In all standard colours. View colours
Custom tray lengths upon request
Option to increase the carrying capacity with Electric Breakaway brakes.
